TOYOTACylinder head gasket112130L010 1121330020 1121330021 1121330040 OIL SEAL

Size：

Oem：112130L010 1121330020 1121330021 1121330040

Application: TOYOTA

Place of Origin: Hebei,china

Advantages: Factory Direct, Factory Price, Standard High Quality Oil Seals

Inquire Now Next Product

Description

Project	Content
Structural position	11381A
OEM	112130L010 1121330020 1121330021 1121330040
HS CODE	8487900000
Material	NBR
Certificate	ISO9001/TS16949
Standard	Standard
Usage location	Cylinder head gasket
Applicable vehicle models	TOYOTA

OEM	brand	Model name	Table of contents	from - to	area	Vehicle Model (Description)
112130L010 1121330020 1121330021 1121330040	Toyota	Model Sub-series	Model Code	Production Period	Applicable Region	Model Number
	Toyota	Model Sub-series	Model Code	Production Period	Applicable Region	Model Number
	Toyota	INNOVA	611260	200408-201606	General Countries	KUN40,TGN4#
	Toyota	INNOVA	611270	201107-201611	General Countries	KUN40,TGN4#
	Toyota	FORTUNER	671380	200501-201204	General Countries	GGN50,60,KUN5#,6#,LAN50,TGN51,61
	Toyota	FORTUNER	6713A0	201107-202110	General Countries	GGN50,60,KUN5#,6#,LAN50,TGN51,61
	Toyota	FORTUNER	6713B0	201507-202104	General Countries	GGN155,165,GUN15#,16#,KUN156,165,LAN155,T..
	Toyota	HILUX	672360	199708-200603	General Countries	KZN165,190,KDN,LN,RZN,YN,VZN14#,15#,16#,17..
	Toyota	HILUX	672370	200408-201204	General Countries	GGN15,25,35,KUN1#,2#,3#,LAN15,25,35,TGN1#,...
	Toyota	HILUX	672370	200408-201204	USA/Canada	GGN15,25,35,KUN1#,2#,3#,LAN15,25,35,TGN...
	Toyota	HILUX	672380	201107-202110	General Countries	GGN15,25,35,KUN1#,2#,3#,LAN15,25,35,TGN1#,...
	Toyota	HILUX	672380	201107-202110	USA/Canada	GGN15,25,35,KUN1#,2#,3#,LAN15,25,35,TGN...
	Toyota	HILUX	672390	201505-202105	General Countries	GGN1###,GUN1###,KUN1###,LAN125,TGN1###
	Toyota	HILUX	672390	201505-202105	USA/Canada	GGN1###,GUN1###,KUN1###,LAN125,TGN1###
	Toyota	HILUX	672570	200507-201204	Europe	KUN15,2#
	Toyota	HILUX	672580	201107-201512	Europe	KUN2#,35

Material Type	Core Advantages	Temperature Range	Key Applications
NBR (Nitrile Butadiene Rubber)	Excellent oil resistance (mineral/animal/vegetable oils), high tensile strength, good wear resistance and elasticity	-40℃~120℃ (short-term 150℃)	Automotive engine oil seals, gearbox oil seals, hydraulic system seals
ACM (Acrylic Ester Rubber)	Superior fuel resistance than NBR, good wear resistance and compression set resistance	-20℃~170℃ (short-term 200℃)	Automotive engine oil seals, fuel system seals, high-temperature condition seals
MVQ (Methyl Vinyl Silicone Rubber)	Outstanding low-temperature resistance, excellent elasticity and aging resistance	-60℃~200℃ (short-term 250℃)	Low-temperature condition seals, food & pharmaceutical equipment seals, insulating seals
FKM (Fluoroelastomer)	Excellent all-round performance, oil/chemical/weather resistance	-20℃~200℃ (250℃ for special grades)	High-temperature & high-pressure seals, chemical equipment seals, extreme automotive condition oil seals

Our core strengths

Globally Sourced Premium Raw Materials, Quality Guaranteed at the SourceWe partner with vetted high-quality raw material suppliers across China and overseas, sourcing premium inputs imported from the U.S., Germany and Southeast Asia. This ensures a solid quality foundation for every product from the very beginning.

Tailor-Made Customization, Precision Engineered for Your NeedsWe offer top-tier custom rubber product solutions, which are precisely engineered to meet the unique operational requirements of diverse scenarios and deliver fully optimized, application-specific products.

Efficient Production & On-Time DeliveryLeveraging our streamlined production system, we enable rapid manufacturing turnaround and strictly adhere to delivery timelines. We guarantee prompt product arrival with zero delays to your project schedules and operational plans.

One-Stop Solution, Driving Cost & Time EfficiencyWe integrate end-to-end services spanning customization, production and after-sales support, complemented by value-added solutions. This helps clients streamline procurement workflows and achieve significant time and cost savings.

Flexible OEM/ODM CapabilitiesWe specialize in R&D, design and manufacturing of a full range of non-standard rubber sealing components based on customer-provided drawings, fully accommodating diverse customization demands.

100% Pre-Shipment Inspection, Uncompromising Quality AssuranceWe implement rigorous quality control standards. All finished rubber products undergo 100% comprehensive inspection prior to shipment, ensuring each unit delivered meets stringent quality benchmarks.

FAQ

Packaging, Delivery & Service Terms

1.Packaging Options

Paper roll packaging: 10 pieces per roll, 200 rolls per carton

PP bag packaging: 50 or 100 pieces per bag, 15 or 30 bags per carton

Carton packaging: 1 piece per box

Custom packaging solutions are available upon customer request.

2.Delivery Lead Time

For in-stock items: Shipment arranged within 1–2 working days

For out-of-stock items with existing molds: Production lead time 10–15 days

For out-of-stock items without existing molds: Production lead time 25–30 days (including mold development)

3.Payment Terms

30% deposit via Telegraphic Transfer (T/T) in advance

70% balance payment to be settled before shipment

Sample-Based Production Capability

We have our own brand DTO, and also accept both ODM and OEM orders. Equipped with comprehensive capabilities covering product analysis, mold development and mass production, we can accurately manufacture products according to the samples provided by customers.
